LD-1300A BOPP tape slitting rewinding machine
This machine is suitable to cut transparent BOPP tape roll and all kinds of printing packing tape.
Specification:500mm / 1000mm / 1300mm
Max. Diameter of unwinding:800mm
Max. Diameter of rewinding:180mm
Min. cut width: 12mm
Paper core diameter: 76.2mm
Output speed: 180m/min
Motor power: 4KW
Voltage: 380V 50HZ
Air pressure: 0.4-0.6MPa
Machine dimension: 2450*1700*1350mm
feature
technical parameter
Technical parameter of LD-1300A BOPP tape slitting rewinding machine:
| Specification | 500mm, 1000mm, 1300mm |
| Max. Diameter of unwinding | 800mm |
| Max. Diameter of rewinding | 180mm |
| Min. cut width | 12mm |
| Paper core diameter | 76.2mm |
| Output speed | 180m/min |
| Motor power | 4KW |
| Voltage | 380V 50HZ |
| Air pressure | 0.4-0.6MPa |
| Machine dimension | 2450*1300*1350mm |
Application
This machine is suitable to cut transparent BOPP packing tape and all kinds of printing packing tape.
production process
auxiliary equipment
Mini rewinder
Suitable for tape improvement, the counter is convenient to set the winding length.
Detail->
Paper core cutting machine
Suitable for paper core cutting; tooth conveyor has good power and low noise; circular knife with cover can keep operator safety.
Detail->
