1000mm BOPP tape manufacturing machine
Suitable for BOPP film printing, coating, cutting and rewinding to produce clear tape, printed tape, color tape or stationery tape.
Coating width：1000mm
Oven length：6M
Voltage：380V 50HZ
Drying method：Electric, gas, oil, steam, stove
Max. Unwinding diameter：600mm
Max. rewinding diameter：300mm
Coating speed：0-30m/min
feature
technical parameter
| Coating width | 1000mm |
| Oven length | 6M |
| Voltage | 380V 50HZ |
| Drying method | Electric, gas, oil, steam, stove |
| Max. Unwinding diameter | 600mm |
| Max. rewinding diameter | 300mm |
| Coating speed | 0-30m/min |
| Motor power | 2.2KW*3 |
| Gross capacity | 25KW |
Application
Suitable for BOPP film printing, coating, cutting and rewinding to produce clear tape, printed tape, color tape or stationery tape.
Raw material: BOPP film, Glue, Paper core
production cost calculation
(the cost is calculated according to our local market on August 2018)
| BOPP film, 1m*4000m, 25micron | 90.5kg/roll, USD 135.8 | Total cost |
| Acrylic glue, 15micron | 105kg glue, USD 103.4 |
40micron, 1m*4000m USD 253 |
| Paper core 3’’, 3mm | USD 0.35/m | |
| One worker, 2.5h working time | USD 6.25 | |
| Electricity 25KW, USD 0.1/KWH | USD 6.25 |
| BOPP film, 1m*4000m, 25micron | 90.5kg/roll, USD 135.8 | Total cost |
| Acrylic glue, 20micron | 140kg glue, USD 137.9 |
45micron, 1m*4000m USD 287 |
| Paper core 3’’, 3mm | USD 0.35/m | |
| One worker, 2.5h working time | USD 6.25 | |
| Electricity 25KW, USD 0.1/KWH | USD 6.25 |
| BOPP film, 1m*4000m, 25micron | 90.5kg/roll, USD 135.8 | Total cost |
| Acrylic glue, 25micron | 175kg glue, USD 172.4 |
50micron, 1m*4000m USD 321 |
| Paper core 3’’, 3mm | USD 0.35/m | |
| One worker, 2.5h working time | USD 6.25 | |
| Electricity 25KW, USD 0.1/KWH | USD 6.25 |
Note: Raw material is from local market, but the big order is cheaper from the producer directly.
production process
auxiliary equipment
Mini rewinder
Suitable for tape improvement, the counter is convenient to set the winding length.
Detail->
Paper core cutting machine
Suitable for paper core cutting; tooth conveyor has good power and low noise; circular knife with cover can keep operator safety.
Detail->
